NEW UHI 3.5TON LITHIUM ELECTRIC FORKLIFT,
3.5TLithium Forklift
* Side shift
* 76.8V 280Ah Rated Battery Capacity
* Optional 3 Phase Charger
Power Model: Electric
Load Capacity: 3500 kg
Load Center: 500 mm
Lift height: 4500 mm
Full free lift height: 1500 mm
Fork dimension: 1070 x 122 x 45 mm
Mast tilting angle: 6 / 12 °
Min. turning radius: 2550 mm
Ground clearance: 135 mm
Overhead guard height: 2165 mm
Front overhang: 495 mm
Max. travel speed: 14/16 km/h
Max. lift speed: 270/320 mm/s
Max. traction power: 17
Max. gradeability: 20%
Total length with fork: 4065 mm
Total length without fork: 2995 mm
Total width: 1225 mm
Mast extended height: 5560 mm
Mast lowered height: 2100 mm
Tyres Front: 28 x 9 – 15 – 12PR
Tyres Rear: 6.50 – 10 – 10PR
Wheelbase: 1700 mm
Tread: 1000 mm / 970 mm
Service weight: 4390 kg
Travel motor: 11 kw
Lift motor: 12 kw
Battery type: Lithium
Rated battery capacity: 76.8V / 280Ah
Max. battery size: 700 x 615 x 330 mm
Motor type: AC
Transmission: Automatic
Work pressure: 18.5 MPa.
